hk.eswl-109
therapy head position innovation
originally designed shock wave source with revolving arm can process fragmentation from both above and under the table, makes it possible for urinary stone, bladder stone and gallstone patients to be treated with a supine posture.
swinging therapy head
the therapy head on revolving arm is capable of swinging in every angle apart from moving with the revolving arm, adds great convenience to positioning and ultrasound localization.
powerful table for separated use
equipped with independent transportable motorized operation table, which is ideal for urological operations.
- description
specification: power supply:a.c. 3n, 380v
total weight:kg
packing dimension:4.5m3
minimum main unit room:5m(l)x5m(w)x2.5m(h)
minimum separate operating room:3m(l)x4m(w)x2.5m(h)
shock wave system
shock wave source
electromagnetic:yes
fine adjustment of energy:yes
penetration depth:130mm
focal pressure:20-72mpa @ 15kv??20kv
coupling mode:dry coupling (cushion)
adjustable shooting frequency:30,60,180shocks/min
patient table
fully motorized movement:yes
minimum height:700mm
vertical movement:150mm
horizontal movement:150mm
forward-backward movement:150mm
therapy head arm revolving angle:
clockwise and counterclockwise 180 degree
therapy head moving along arm:250mm
therapy head swing angle:plus/minus 45 degree
table side button control:yes
uro kit for operation:yes
ultrasound system
installation:outline
high resolution monitor:yes
auxiliary equipment:keyboard, trackball
scanning method:convex sector
display mode:b, b/m, m,b b
probe frequency:3.5mhz with 5.0mhz and 7.5mhz optional
focusing method:4-step focusing with variable aperture, lens focusing
zooming:´1, ´1.2, ´1.5, ´2 as well as depth shift
image processing:pre-processing, correlation-processing, interpolation
measuring function, distance, area, circumference, heart rate etc.
body mark, 8 kinds of probe mark display
character display id, date, time, frequency, gain, zoom, focus, etc.
power supply:110v/220v
power:320va
application: kidney stone,bladder stone,urinary stone etc configuration: on request. consumables: em disk, lens, cushion,hv unit
 |
|
 |
